5 Port 10/100/1000Mbps Switch Networks, Racks and Accessories

Name: 5 Port 10/100/1000Mbps Switch Networks, Racks and Accessories
Brand: Tp-link
SKU: DGS-105
Price: 28.71 EUR
Availability: OutOfStock

TP-LINK DGS-105

Sold out

28,71 €

Description

Features:

Unmanaged switches with IGMP Snooping enabled.
Designed for home or small business environments with IPTV
Common situation: when watching IPTV, the network, and especially Wi-Fi, is affected: IPTV multicast traffic propagates throughout the network, impacting the performance of all our devices.
Using a DGS-105 or DGS-108, multicast traffic will reach the TV Set-Top Box.
Metal casing
Includes grounding screw

Specifications:

Standards
- IEEE 802.3 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet
- ANSI / IEEE 802.3 NWay auto-negotiation
IEEE 802.3x flow control
- IEEE 802.3az Energy Efficient Ethernet (EEE)
Layer2 Features
MAC Address Table: 2K
Auto MDI/MDIX crossover for all ports
Store and forward switching scheme half-duplex / full for Ethernet / Fast Ethernet speeds
Full-duplex only for Gigabit Ethernet speed
Jumbo Frames: 9000 Bytes
Switching Fabric 10 Gbps
Data Transfer Rates
- Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
- Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full-duplex)
- Gigabit Ethernet: 2000 Mbps (full-duplex)
- Packet filtering / transmission rates
- Ethernet: 14,880 pps per port
- Fast Ethernet: 148,800 pps per port
- Gigabit Ethernet: 1,488,000 pps per port
RAM Buffer 128 KB
LED Indicators
- Per port: link / activity / speed
- Per device: Power
- Quality of Service (QoS)
- Supports 802.1p QoS
- 4 queues, Strict Mode
Eco-friendly features
- Energy Efficient Ethernet standard (EEE)
- D-Link Green: power saving by detecting cable length
- RoHS
Power
- External 5 V / 1 A Level "V" power adapter
- Power Consumption (DC input)
- Standby: 0.5 W.
- Maximum: 2.01 W
MTBF 1,688,338 hours
Temperature
- Operating: 0 to 50 ° C
- Storage: -10 to 70 ° C
Humidity
- Operating: 10% to 90% RH non-condensing
- Storage: 5% to 90% RH non-condensing
Dimensions (W x D x H) 100 x 98 x 28 mm
Certifications
- FCC Class B
- ICES-003 Class B
- CE Class B
- C-Tick Class B
- VCCI Class B
- cUL
- CB
