| Brand
|
Hikvision |
| Range
|
PRO |
| IP camera inputs
|
8-port switch |
| PoE Power Supply |
8-port PoE IEEE802.3af/at switch (max. 75W) |
| Compatible IP Cameras
|
HIKVISION (native protocol), ONVIF |
| Two-way audio
|
1 RCA output |
| Video outputs
|
1xHDMI 4K, 1xVGA simultaneous |
| Video compression format
|
H.265+ / H.265 / H.264+ / H.264 |
| Display resolution
|
HDMI: 4096x2160, 3840x2160, 2560x1440, 1920x1080, 1600x1200, 1280x1024, 1280x720
VGA: 1920x1080, 1280x1024, 1280x720 |
| Total bandwidth
|
80 Mbps input / 80 Mbps output |
| Stream Type
|
Video / Video + Audio |
| Main Stream Recording
|
8MP /6MP /5MP /4MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Decoding ability
|
1CH@8MPx, 3CH@4MP, 6CH@1080p |
| Simultaneous multifunction
|
Pentaplex: Live Streaming, Recording, Playback, Backup, and Remote Access |
| Motion detection
|
Motion Detection 2.0 with human and vehicle classification applied to motion detection.
Available on up to 4 channels.
* Motion detection and Acusense cannot be enabled at the same time on the same device. |
| Alarms
|
4 Inputs / 1 Relay |
| Recording method
|
Manual, programmed, motion detection |
| External backup
|
USB Memory / USB HDD / USB CD-RW / USB DVR-RW |
| Remote access
|
Web Browser, Hik-Connect Smartphone App, iVMS-4200 PC Software and Hik-Central |
| Remote connections
|
32 |
| Internal storage
|
1 x 3.5" SATA HDD up to 8 TB (not included) |
| Communication
|
2 x USB 2.0 / 1 x RJ45 10/100M (Ethernet) |
| Feeding
|
DC 48 V / 1.88 A, ≤ 10 W (without HDD) |
| Operating temperature
|
-10ºC ~ 55ºC (10%-90% Humidity) |
| Dimensions / Weight
|
48 (H) x 320 (W) x 240 (D) mm / 1 Kg (without HDD) |
