IK09 Access Control | EM/MF Card, NFC, BLE, PIN and QR Code | 1 Relay | 20,000 Users | 100,000 Records

383,00 €
Akuvox  |  SKU: AK-A08S

Estimated delivery 1 to 5 business days after order

Description

Integrated controller

Wiegand 26/34

Suitable for outdoor use IP65

TCP/IP and PoE

Cloud connection

12V Output

Brand Akuvox
Model A08S
Access control Door opening with RFID card EM 125 kHz and MF 13.56 MHz, NFC, PIN, Bluetooth and QR, with logs
Ability Up to 20,000 users and 20,000 cards
Records 100,000 records
Communication TCP/IP, Wiegand
Departures Wiegand OUT, 1 relay for main lock and RS485
Tickets Wiegand IN, 2 pushbuttons, 1 tamper
Advanced Features Anti-passback (configurable via Cloud, in Office Project)
Remote access SmartPlus mobile app or setup via web browser
Remote access via Cloud: Yes, available
Audio Opening message speaker
Network interface Ethernet 10/100 BaseT
Operating mode local network and/or via cloud across different networks
Firmware updates Remotely via cloud using an installer account or via a local web browser
Material Plastic (body), aluminum alloy (frame) and tempered glass (front)
Level of protection IP65 and IK09
Operating temperature -20º C ~ +55º C
Dimensions 140 (H) x 50 (W) x 27 (D) mm
Feeding DC 12 V / 1000 mA max. /PoE IEEE802.3af
Weight 325 g
