Ajax Hub 2 (2G) alarm control panel, the control panel for the Ajax wireless security system with photo verification. In addition to the two-way Jeweller protocol, it incorporates the Wings protocol, which allows receiving images from motion detectors with a camera (MotionCam) to visually confirm alarms. It coordinates up to 100 devices with a radio range of up to 2000 m in open space, is fully managed from the Ajax app (iOS and Android), and offers communication redundancy via Ethernet and two 2G SIM cards.
Main features:
- Photo verification: receives images from MotionCam detectors via the Wings protocol.
- Jeweller and Wings (868 MHz) two-way wireless protocols, with a range of up to 2000 m in open space.
- Triple communication channel: Ethernet + two 2G SIMs, with automatic failover switching.
- Manages up to 100 devices, 50 users, and 9 security groups.
- Up to 10 sirens/keypads and 5 ReX radio signal range extenders.
- Integration with up to 25 IP cameras or DVR channels.
- Frequency hopping and block encryption with a dynamic key against interference and sabotage.
- Communication with ARC via Contact ID and SIA protocols.
- OS Malevich operating system, immune to viruses, with remote OTA updates.
- Security Grade 2 (EN 50131), SmartBracket mounting with tamper and backup battery for up to 16 hours.
Specifications:
| Brand |
AJAX |
| Model |
Hub 2 (2G) — AJ-HUB2-W |
| RF protocol |
Jeweller and Wings, 868 MHz (two-way) |
| Radio range |
Up to 2000 m in open space |
| Photo verification |
Yes (MotionCam detectors) |
| Security Grade |
Grade 2 (EN 50131) |
| Internal security |
Anti-opening tamper |
| Internal siren |
Not available |
| Communication |
Ethernet + Dual SIM 2G (GPRS) |
| Maximum number of devices |
100 (up to 10 sirens/keypads and 5 ReX range extenders) |
| Video integration |
Up to 25 IP cameras or DVR channels |
| Number of users |
Up to 50 (9 security groups) |
| Communication with ARC |
Contact ID / SIA |
| Compatibility |
Not compatible with ocBridge or uartBridge |
| Firmware update |
OTA (over-the-air) remotely — OS Malevich |
| Housing material |
ABS plastic |
| Power supply |
AC 110–240 V, 50/60 Hz |
| Backup battery |
Li-ion 2 Ah, up to 16 hours |
| Operating temp. |
-10 °C ~ +40 °C |
| Dimensions |
163 (H) × 163 (W) × 36 (D) mm |
| Color |
White |
Package contents:
- 1x Ajax Hub 2 (2G) control panel
- SmartBracket mounting panel
- Power cable
- Ethernet cable
- Installation kit (screws)
- Quick start guide
